Create the desired lighting effect in your stores with IKIO’s Orwin, a circular LED ambient light made of aluminum die cast with high quality powder coated luminaire housing and optimum heat sink. These properties of the luminaire contribute to its effective functioning for a longer time period. Moreover, available in multiple wattages, color temperatures, finishes, and beam angles, this luminaire offers greater flexibility in its application.
• Even light distribution without halo and shadows.
• Suitable for wet locations.
• Excellent heat dissipation with flicker-free light.
• Incorporates intelligent control technology.
| Efficacy (lm/W) |
6" - Up to 90.24 lm/W 8" - Up to 95.64 lm/W 10" - Up to 93.83 lm/W |
| Power (W) |
6" - 12 W-17 W-22 W 8" - 17 W-24 W - 30 W 10" - 22 W - 30 W - 38 W |
| CCT (K) | 2700 K-3000 K-3500 K-4000 K-5000 K |
| CRI | >90 |
| Voltage | AC 120-277 V 50/60 Hz |
| Beam Angle | 100° |
| Dimming | 0-10 V |
| Operating Temperature | -14° F to +122° F |
| Power | SKU Number | Efficacy | CCT | Voltage | Lumen Output | Distribution/ Beam angle | Finish | Size | Diffuser | Ordering Part Number | Technical Data Sheet | IES File |
| 12 W-17 W-22 W | 662187477466 | 90.24 lm/W-87.50 lm/W-84.68 lm/W | 2700 K-3000 K-3500 K-4000 K-5000 K | 120-277 V | 1045 lm-1484 lm-1790.2 lm | 100° | White | 6" | Frosted | IK-DLR6L-121722-CCT | Download | Download |
| 17 W-24 W-30 W | 662187477459 | 95 lm/W-90 lm/W-95.64 lm/W | 3000 K-4000 K-5000 K | 120-277 V | 1615 lm-2160 lm- 2587 lm | 100° | White | 8" | Frosted | IK-DLR8L-172430-CCT | Download | Download |
| 22 W-30 W-38 W | 662187478753 | 93.83 lm/W-91.50 lm/W-89.11 lm/W | 2700 K-3000 K-3500 K-4000 K-5000 K | 120-277 V | 2006 lm-2583 lm-3199.0 lm | 100° | White | 10" | Frosted | IK-DLR10L-223038-CCT | Download | Download |
