The Forza Square High Bay is rated and certified for use in all types of hazardous applications. This luminaire is designed for pole, suspended, wall or yoke mounting with optic options for task or general area illumination. Its body is made of aluminum alloy by die casting, and the surface is sprayed with marine rated powder coating. This luminaire comes with 5 years of warranty and can be used as floodlight, wall pack or area light to provide general illumination in hazardous locations.
| Efficacy (lm/W) | 140 lm/W |
| Varient & Power (W) |
Forza 1 (A1L140) - 20 W, 40 W, 60 W Forza 2 (A2L140) - 80 W, 100 W Forza 3 (A3L140) - 150 W, 200 W Forza 4 (A4L140) - 250 W, 400 W |
| CCT (K) | 4000 K, 5000 K |
| CRI | 80 |
| Voltage | 100-277 V AC 50/60 Hz (200-480 V fixtures also available) |
| Beam Angle | 120° (40°, 60°, 90°, can be made as per request) |
| Operating Temperature | -40° F to +131° F |
| IP Rating | IP66 |
| IK Rating | IK08 |
| Housing | Aluminum |
