Neron Area Light
CLASS I DIVISION 2

The Neron Explosion Proof Area Light is designed for installation in Class I, II and III hazardous environments, their innovative design provides high energy efficiency, superior lighting quality, and a longer operating life. Manufactured in accordance with the European Directive (ATEX) and IECEx standards, they are designed for general outdoor illumination duties at medium and high suspension heights. They also offer a high color rendition index compared to high-pressure sodium lamps.

PRODUCT FEATURES

Classifications / Ratings

  • Class I, Divison 2, Groups A, B,C, D
  • Class II, Division 1, Groups E, F, G
  • Class II, Division 2, Groups F, G
  • Class III
  • II 2 G Ex ec mb IIC T6...T3 Gc
  • II 2 D Ex tb IIIC T80°C...T125°C Db6
  • Temperature Rating C1D2 T6
Product Details
Efficacy (lm/W) 140 lm/W
Varient & Power (W)

Neron 1 (STA1L140) - 100 W

Neron 2 (STA2L140) - 150 W, 200 W, 240 W

CCT (K) 4000 K, 5000 K
CRI 70
Voltage 100-305 V AC 50/60 Hz
Beam Angle 120°
Operating Temperature -40° F to +140° F
IP Rating IP66
IK Rating IK09
Housing Aluminum
Technical Resources
Specification Sheet
