IKIO Simplex Linear Low Bay provides multiple lumen packages and distributions to give the necessary optical freedom and flexibility to meet a variety of lighting needs. It is a direct replacement of traditional fluorescent tubes.
| Efficacy (lm/W) | 135 lm/W |
| Power (W) | 40 W, 60 W |
| CCT (K) | 3000 K, 3500 K, 4000 K, 5000 K |
| CRI | 80+ |
| Voltage | AC 100-277 V 50/60 Hz |
| Beam Angle | 180° |
| Dimming | Yes |
| Operating Temperature | -4° F to +122° F |
| IP Rating | IP40 |
| Housing | Aluminum and Metal sheet |
| Power | SKU Number | CCT | Voltage | Lumen Output | Beam Angle | Finish | Qualified part number | Ordering part number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|---|---|
| 40 W | 662187528335 | 3000 K | AC 100-277 V | 5400 lm | 180° | White | Not Qualified Yet | IK-ST04-0040-30-J | Download | Download |
| 40 W | 662187535913 | 3500 K | AC 100-277 V | 5400 lm | 180° | White | Not Qualified Yet | IK-ST04-0040-35-J | Download | Download |
| 40 W | 662187549156 | 4000 K | AC 100-277 V | 5400 lm | 180° | White | Not Qualified Yet | IK-ST04-0040-40-J | Download | Download |
| 40 W | 662187559018 | 5000 K | AC 100-277 V | 5400 lm | 180° | White | Not Qualified Yet | IK-ST04-0040-50-J | Download | Download |
| 60 W | 662187535968 | 3000 K | AC 100-277 V | 8100 lm | 180° | White | Not Qualified Yet | IK-ST08-0060-30-J | Download | Download |
| 60 W | 662187535975 | 3500 K | AC 100-277 V | 8100 lm | 180° | White | Not Qualified Yet | IK-ST08-0060-35-J | Download | Download |
| 60 W | 662187548524 | 4000 K | AC 100-277 V | 8100 lm | 180° | White | Not Qualified Yet | IK-ST08-0060-40-J | Download | Download |
| 60 W | 662187508122 | 5000 K | AC 100-277 V | 8100 lm | 180° | White | Not Qualified Yet | IK-ST08-0060-50-J | Download | Download |
