T8 Tube
Type A&B

IKIO T8 Tube – Type A&B is designed for a direct replacement of the existing T8 fluorescent lighting systems. It is offered in a variety of color temperatures for flexibility in all types of applications. Available options of frosted and clear lens allow for an evenly illuminated glow, resembling existing fluorescent tubes. The tube is fitted with an internal IKIO driver that works with an electronic ballast or with in-line voltage.

PRODUCT FEATURES

  • Can be rewired in a few simple steps to run on line voltage.
  • Can also be used with existing instant start ballasts.
  • Uniform and smooth light without any flickering, and excellent efficacy.
  • Dual Mode Internal Driver (UL Type A and Type B).
Product Details
Efficacy (lm/W) 160 lm/W, 175lm/W
Power (W) 12 W, 15 W, 18 W, 20 W
CCT (K) 3000 K, 3500 K, 4000 K, 5000 K
CRI 80+
Voltage AC 100-277 V 50/60 Hz
Beam Angle 180°
Dimming No
Operating Temperature -13° F to +113° F
IP Rating IP20
Housing Aluminum + Polycarbonate
Technical Resources
Product Sheet

T8_Tubes_Type_A&B_PS.pdf

LM79 Reports

LM79_T8_Tube_Type_A&B.zip

Installation Instructions

T8_Tube_Type_A&B_Installation Instructions.zip

SKU Details
Power SKU Number CCT Model Efficacy Voltage Lumen Output (lm) Size Qualified part number Ordering part number Technical Data Sheet IES File
12 W 662187533247 3000 K T8 Tube Type A&B 160 lm/W AC 100-277 V 1920 lm 4 ft IK-T804-0012-30A&B-SF IK-T804-0012-30A&B-SF (Frosted) Download Download
12 W 662187475509 3500 K T8 Tube Type A&B 160 lm/W AC 100-277 V 1920 lm 4 ft IK-T804-0012-35A&B-SF IK-T804-0012-35A&B-SF (Frosted) Download Download
12 W 662187533254 4000 K T8 Tube Type A&B 160 lm/W AC 100-277 V 1920 lm 4 ft IK-T804-0012-40A&B-SF IK-T804-0012-40A&B-SF (Frosted) Download Download
12 W 662187547763 5000 K T8 Tube Type A&B 160 lm/W AC 100-277 V 1920 lm 4 ft IK-T804-0012-50A&B-SF IK-T804-0012-50A&B-SF (Frosted) Download Download
12 W 662187533261 3000 K T8 Tube Type A&B 160 lm/W AC 100-277 V 1920 lm 4 ft IK-T804-0012-30A&B-SC IK-T804-0012-30A&B-SC (Clear) Download On Request
12 W 662187548388 3500 K T8 Tube Type A&B 160 lm/W AC 100-277 V 1920 lm 4 ft IK-T804-0012-35A&B-SC IK-T804-0012-35A&B-SC (Clear) Download On Request
12 W 662187548081 4000 K T8 Tube Type A&B 160 lm/W AC 100-277 V 1920 lm 4 ft IK-T804-0012-40A&B-SC IK-T804-0012-40A&B-SC (Clear) Download On Request
12 W 662187553740 5000 K T8 Tube Type A&B 160 lm/W AC 100-277 V 1920 lm 4 ft IK-T804-0012-50A&B-SC IK-T804-0012-50A&B-SC (Clear) Download On Request
15 W 662187465166 3000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2400 lm 4 ft IK-T804-0015-30A&B-SC IK-T804-0015-30A&B-SC (Clear) Download Download
15 W 662187465173 3500 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2400 lm 4 ft IK-T804-0015-35A&B-SC IK-T804-0015-35A&B-SC (Clear) Download Download
15 W 662187465180 4000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2400 lm 4 ft IK-T804-0015-40A&B-SC IK-T804-0015-40A&B-SC (Clear) Download Download
15 W 662187465197 5000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2400 lm 4 ft IK-T804-0015-50A&B-SC IK-T804-0015-50A&B-SC (Clear) Download Download
15 W 662187465203 3000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2400 lm 4 ft IK-T804-0015-30A&B-SF IK-T804-0015-30A&B-SF (Frosted) Download Download
15 W 662187465210 3500 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2400 lm 4 ft IK-T804-0015-35A&B-SF IK-T804-0015-35A&B-SF (Frosted) Download Download
15 W 662187465227 4000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2400 lm 4 ft IK-T804-0015-40A&B-SF IK-T804-0015-40A&B-SF (Frosted) Download Download
15 W 662187465234 5000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2400 lm 4 ft IK-T804-0015-50A&B-SF IK-T804-0015-50A&B-SF (Frosted) Download Download
18 W 662187465241 3000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2880 lm 4 ft IK-T804-0018-30A&B-SC IK-T804-0018-30A&B-SC (Clear) Download Download
18 W 662187465258 3500 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2880 lm 4 ft IK-T804-0018-35A&B-SC IK-T804-0018-35A&B-SC (Clear) Download Download
18 W 662187465265 4000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2880 lm 4 ft IK-T804-0018-40A&B-SC IK-T804-0018-40A&B-SC (Clear) Download Download
18 W 662187465272 5000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2880 lm 4 ft IK-T804-0018-50A&B-SC IK-T804-0018-50A&B-SC (Clear) Download Download
18 W 662187465296 3000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2880 lm 4 ft IK-T804-0018-30A&B-SF IK-T804-0018-30A&B-SF (Frosted) Download Download
18 W 662187465302 3500 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2880 lm 4 ft IK-T804-0018-35A&B-SF IK-T804-0018-35A&B-SF (Frosted) Download Download
18 W 662187465319 4000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2880 lm 4 ft IK-T804-0018-40A&B-SF IK-T804-0018-40A&B-SF (Frosted)- Download Download
18 W 662187465326 5000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2880 lm 4 ft IK-T804-0018-50A&B-SF IK-T804-0018-50A&B-SF (Frosted) Download Download
20 W 662187465333 3000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3200 lm 4 ft Not Qualified IK-T804-L160-0020-DN-30A&B-J (Clear) Download Download
20 W 662187465340 3500 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3200 lm 4 ft Not Qualified IK-T804-L160-0020-DN-35A&B-J (Clear) Download On Request
20 W 662187465364 4000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3200 lm 4 ft Not Qualified IK-T804-L160-0020-DN-40A&B-J (Clear) Download On Request
20 W 662187465371 5000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3200 lm 4 ft Not Qualified IK-T804-L160-0020-DN-50A&B-J (Clear) Download On Request
20 W 662187465388 3000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3200 lm 4 ft Not Qualified IK-T804-L160-0020-DN-30A&B-J (Frosted) Download Download
20 W 662187465401 3500 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3200 lm 4 ft Not Qualified IK-T804-L160-0020-DN-35A&B-J (Frosted) Download On Request
20 W 662187465418 4000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3200 lm 4 ft Not Qualified IK-T804-L160-0020-DN-40A&B-J (Frosted) Download On Request
20 W 662187465425 5000 K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3200 lm 4 ft Not Qualified IK-T804-L160-0020-DN-50A&B-J (Frosted) Download On Request
12 W 662187481050 4500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2100 lm 4 ft IK-T804-0012-45A&B-SC IK-T804-0012-45A&B-SC (Clear) Download On Request
12 W 662187481067 4500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 1806 lm 4 ft IK-T804-0012-45A&B-SF  IK-T804-0012-45A&B-SF (Frosted)  Download On Request
12 W 662187481074 6500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2100 lm 4 ft IK-T804-0012-65A&B-SC IK-T804-0012-65A&B-SC (Clear) Download On Request
12 W 662187481081 6500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 1806 lm 4 ft IK-T804-0012-65A&B-SF  IK-T804-0012-65A&B-SF (Frosted)  Download On Request
15 W 662187481098 4500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2550 lm 4 ft IK-T804-0015-45A&B-SC IK-T804-0015-45A&B-SC (Clear) Download On Request
15 W 662187481104 4500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2176 lm 4 ft IK-T804-0015-45A&B-SF IK-T804-0015-45A&B-SF (Frosted)- Download On Request
15 W 662187481111 6500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2550 lm 4 ft IK-T804-0015-65A&B-SC IK-T804-0015-65A&B-SC (Clear) Download On Request
15 W 662187481135 6500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2176 lm 4 ft IK-T804-0015-65A&B-SF IK-T804-0015-65A&B-SF (Frosted) Download On Request
18 W 662187481142 4500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3000 lm 4 ft IK-T804-0018-45A&B-SC IK-T804-0018-45A&B-SC (Clear) Download On Request
18 W 662187481159 4500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2700 lm 4 ft IK-T804-0018-45A&B-SF IK-T804-0018-45A&B-SF (Frosted) Download On Request
18 W 662187481166 6500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 3000 lm 4 ft IK-T804-0018-65A&B-SC IK-T804-0018-65A&B-SC (Clear) Download On Request
18 W 662187481173 6500K T8 Tube Type A&B 160 lm/W 160 lm/W AC 100-277 V 2700 lm 4 ft IK-T804-0018-65A&B-SF IK-T804-0018-65A&B-SF (Frosted) Download On Request
12 W 662187533384 3000 K T8 Tube Type A&B 175 lm/W 175 lm/W AC 100-277 V 2100 lm 4 ft Not Qualified IK-T804-L175-0012-DN-30A&B-J (Clear) Download Download
12 W 662187533391 3500 K T8 Tube Type A&B 175 lm/W 175 lm/W AC 100-277 V 2100 lm 4 ft Not Qualified IK-T804-L175-0012-DN-35A&B-J (Clear) Download On Request
12 W 662187533407 4000 K T8 Tube Type A&B 175 lm/W 175 lm/W AC 100-277 V 2100 lm 4 ft Not Qualified IK-T804-L175-0012-DN-40A&B-J (Clear) Download On Request
12 W 662187533414 5000 K T8 Tube Type A&B 175 lm/W 175 lm/W AC 100-277 V 2100 lm 4 ft Not Qualified IK-T804-L175-0012-DN-50A&B-J (Clear) Download On Request
12 W 662187533421 3000 K T8 Tube Type A&B 175 lm/W 175 lm/W AC 100-277 V 2100 lm 4 ft Not Qualified IK-T804-L175-0012-DN-30A&B-J (Frosted) Download Download
12 W 662187533438 3500 K T8 Tube Type A&B 175 lm/W 175 lm/W AC 100-277 V 2100 lm 4 ft Not Qualified IK-T804-L175-0012-DN-35A&B-J (Frosted) Download On Request
12 W 662187533445 4000 K T8 Tube Type A&B 175 lm/W 175 lm/W AC 100-277 V 2100 lm 4 ft Not Qualified IK-T804-L175-0012-DN-40A&B-J (Frosted) Download On Request
12 W 662187533452 5000 K T8 Tube Type A&B 175 lm/W 175 lm/W AC 100-277 V 2100 lm 4 ft Not Qualified IK-T804-L175-0012-DN-50A&B-J (Frosted) Download On Request
