IKIO T8 Tube – Type B is designed for direct replacement of existing T8 fluorescent lighting systems. IKIO tube is offered in a variety of color temperatures for flexibility in all types of applications. Available options of frosted and clear lens allow for an evenly illuminated glow, resembling existing fluorescent tubes. The tube is fitted with an internal IKIO driver that works with in-line voltage.
| Efficacy (lm/W) | Up to 173 lm/W * Efficacy/Lumens can vary per item, see technical data sheets (TDS) for specific information |
| Power (W) | 12W, 15W, 18W |
| CCT (K) | 3000K, 3500K, 4000 K, 5000 K, 6500K |
| CRI | 80+ |
| Voltage | AC 100-277 V 50/60 Hz |
| Beam Angle | Up to 155° * can vary per item, see technical data sheets (TDS) for specific information |
| Dimming | Continuous Dimming to 10% or below * Controller required. (Ordered Separately) |
| Operating Temperature | -4° F to +104° F |
| IP Rating | IP20 |
| Housing | Aluminum + Polycarbonate |
| Power | SKU Number | CCT | Diffuser | Lumen Output | Ordering part number | Qualified part number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|
| 11.5 W | 662187539645 | 3000 K | Frosted | 1832 lm | IK-T804-0012-30B-SF (Frosted) | IK-T804-0012-30B-SF | Download | Download |
| 11.5 W | 662187539775 | 3500 K | Frosted | 1856 lm | IK-T804-0012-35B-SF (Frosted) | IK-T804-0012-35B-SF | Download | Download |
| 11.5 W | 662187477695 | 4000 K | Frosted | 1881 lm | IK-T804-0012-40B-SF (Frosted) | IK-T804-0012-40B-SF | Download | Download |
| 11.5 W | 662187477688 | 5000 K | Frosted | 1929 lm | IK-T804-0012-50B-SF (Frosted) | IK-T804-0012-50B-SF | Download | Download |
| 11.5 W | 662187539874 | 6500 K | Frosted | 1978 lm | IK-T804-0012-65B-SF (Frosted) | IK-T804-0012-65B-SF | Download | Download |
| 12 W | 662187539881 | 3000 K | Clear | 1936 lm | IK-T804-0012-30B-SC (Clear) | IK-T804-0012-30B-SC | Download | Download |
| 12 W | 662187539782 | 3500 K | Clear | 1959 lm | IK-T804-0012-35B-SC (Clear) | IK-T804-0012-35B-SC | Download | Download |
| 12 W | 662187539751 | 4000 K | Clear | 1985 lm | IK-T804-0012-40B-SC (Clear) | IK-T804-0012-40B-SC | Download | Download |
| 12 W | 662187539652 | 5000 K | Clear | 2035 lm | IK-T804-0012-50B-SC (Clear) | IK-T804-0012-50B-SC | Download | Download |
| 12 W | 662187539867 | 6500 K | Clear | 2083 lm | IK-T804-0012-65B-SC (Clear) | IK-T804-0012-65B-SC | Download | Download |
| 15.2 W | 662187539829 | 3000 K | Frosted | 2365 lm | IK-T804-0015-30B-SF (Frosted) | IK-T804-0015-30B-SF | Download | Download |
| 15.2 W | 662187539836 | 3500 K | Frosted | 2393 lm | IK-T804-0015-35B-SF (Frosted) | IK-T804-0015-35B-SF | Download | Download |
| 15.2 W | 662187539614 | 4000 K | Frosted | 2424 lm | IK-T804-0015-40B-SF (Frosted) | IK-T804-0015-40B-SF | Download | Download |
| 15.2 W | 662187539720 | 5000 K | Frosted | 2485 lm | IK-T804-0015-50B-SF (Frosted) | IK-T804-0015-50B-SF | Download | Download |
| 15.2 W | 662187539744 | 6500 K | Frosted | 2544 lm | IK-T804-0015-65B-SF (Frosted) | IK-T804-0015-65B-SF | Download | Download |
| 15 W | 662187539843 | 3000 K | Clear | 2366 lm | IK-T804-0015-30B-SC (Clear) | IK-T804-0015-30B-SC | Download | Download |
| 15 W | 662187539737 | 3500 K | Clear | 2395 lm | IK-T804-0015-35B-SC (Clear) | IK-T804-0015-35B-SC | Download | Download |
| 15 W | 662187539928 | 4000 K | Clear | 2425 lm | IK-T804-0015-40B-SC (Clear) | IK-T804-0015-40B-SC | Download | Download |
| 15 W | 662187539676 | 5000 K | Clear | 2487 lm | IK-T804-0015-50B-SC (Clear) | IK-T804-0015-50B-SC | Download | Download |
| 15 W | 662187539706 | 6500 K | Clear | 2546 lm | IK-T804-0015-65B-SC (Clear) | IK-T804-0015-65B-SC | Download | Download |
| 17.8 W | 662187539713 | 3000 K | Frosted | 2741 lm | IK-T804-0018-30B-SF (Frosted) | IK-T804-0018-30B-SF | Download | Download |
| 18 W | 662187539911 | 3500 K | Frosted | 2772 lm | IK-T804-0018-35B-SF (Frosted) | IK-T804-0018-35B-SF | Download | Download |
| 18 W | 662187477718 | 4000 K | Frosted | 2804 lm | IK-T804-0018-40B-SF (Frosted) | IK-T804-0018-40B-SF | Download | Download |
| 18 W | 662187477701 | 5000 K | Frosted | 2867 lm | IK-T804-0018-50B-SF (Frosted) | IK-T804-0018-50B-SF | Download | Download |
| 18.1 W | 662187539638 | 6500 K | Frosted | 2930 lm | IK-T804-0018-65B-SF (Frosted) | IK-T804-0018-65B-SF | Download | Download |
| 18.4 W | 662187539607 | 3000 K | Clear | 2864 lm | IK-T804-0018-30B-SC (Clear) | IK-T804-0018-30B-SC | Download | Download |
| 18.4 W | 662187539799 | 3500 K | Clear | 2899 lm | IK-T804-0018-35B-SC (Clear) | IK-T804-0018-35B-SC | Download | Download |
| 18.4 W | 662187539805 | 4000 K | Clear | 2936 lm | IK-T804-0018-40B-SC (Clear) | IK-T804-0018-40B-SC | Download | Download |
| 18.4 W | 662187539690 | 5000 K | Clear | 3010 lm | IK-T804-0018-50B-SC (Clear) | IK-T804-0018-50B-SC | Download | Download |
| 18.4 W | 662187539621 | 6500 K | Clear | 3082 lm | IK-T804-0018-65B-SC (Clear) | IK-T804-0018-65B-SC | Download | Download |
