IKIO Striza Magnetic Strip Kit is an economy-level LED retrofit for 2’x 2’ & 2′ x 4′ recessed and surface mounted troffers or any linear fluorescent fixture. These kits are easy to install using simple hand tools with minimum modification to the existing housing.
| Efficacy (lm/W) | 110 lm/W |
| Power (W) | 10 W, 15 W, 20 W |
| CCT (K) | 4000 K, 5000 K |
| CRI | 80+ |
| Voltage | AC 100-277 V 50/60 Hz (Driver Required) |
| Beam Angle | 120° |
| Dimming | 0-10 V, Range 10% - 100% |
| Operating Temperature | -04° F to +122° F |
| IP Rating | IP40 |
| Housing | Aluminum and Metal sheet |
| Power | SKU Number | CCT | Voltage | Lumen Output | Beam Angle | Size | Diffuser | Strip | Qualified part number | Ordering part number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10 W | 662187534930 | 4000 K | AC 100-277 V | 1100 lm | 120° | 2 ft | Frosted | 2 | Not Qualified Yet | IK-MS02-0010-2-DY-40-J | Download | On Request |
| 10 W | 662187534947 | 5000 K | AC 100-277 V | 1100 lm | 120° | 2 ft | Frosted | 2 | Not Qualified Yet | IK-MS02-0010-2-DY-50-J | Download | On Request |
| 10 W | 662187535081 | 4000 K | AC 100-277 V | 1100 lm | 120° | 2 ft | Frosted | 4 | Not Qualified Yet | IK-MS02-0010-4-DY-40-J | Download | Download |
| 10 W | 662187535098 | 5000 K | AC 100-277 V | 1100 lm | 120° | 2 ft | Frosted | 4 | Not Qualified Yet | IK-MS02-0010-4-DY-50-J | Download | Download |
| 15 W | 662187535326 | 4000 K | AC 100-277 V | 1650 lm | 120° | 4 ft | Frosted | 2 | Not Qualified Yet | IK-MS04-0015-2-DY-40-J | Download | Download |
| 15 W | 662187535333 | 5000 K | AC 100-277 V | 1650 lm | 120° | 4 ft | Frosted | 2 | Not Qualified Yet | IK-MS04-0015-2-DY-50-J | Download | Download |
| 15 W | 662187535470 | 4000 K | AC 100-277 V | 1650 lm | 120° | 4 ft | Frosted | 4 | Not Qualified Yet | IK-MS04-0015-4-DY-40-J | Download | Download |
| 15 W | 662187535487 | 5000 K | AC 100-277 V | 1650 lm | 120° | 4 ft | Frosted | 4 | Not Qualified Yet | IK-MS04-0015-4-DY-50-J | Download | Download |
| 20 W | 662187495095 | 4000 K | AC 100-277 V | 2200 lm | 120° | 4 ft | Frosted | 2 | Not Qualified Yet | IK-MS04-002022-2-DY-40-J | Download | Download |
| 20 W | 662187495149 | 5000 K | AC 100-277 V | 2200 lm | 120° | 4 ft | Frosted | 2 | Not Qualified Yet | IK-MS04-002022-2-DY-50-J | Download | Download |
| 20 W | 662187535685 | 4000 K | AC 100-277 V | 2200 lm | 120° | 4 ft | Frosted | 4 | Not Qualified Yet | IK-MS04-002022-4-DY-40-J | Download | Download |
| 20 W | 662187535692 | 5000 K | AC 100-277 V | 2200 lm | 120° | 4 ft | Frosted | 4 | Not Qualified Yet | IK-MS04-002022-4-DY-50-J | Download | Download |
