Delphi Semi Cutoff Wall Pack, a highly efficient LED Lighting solution, is designed with superior light controls as it allows its users to switch to different CCTs and wattages to suit their requirements. This new CCT & power selectable LED wall pack enables easy application in multiple areas. The rugged housing of this luminaire offers advanced thermal management & protection against outdoor environments without compromising with its aesthetics.
• CCT & power selectable capabilities.
• Excellent light output with even and wide distribution.
• Saves greater energy over the traditional lighting fixtures.
• Suitable for operation in low working temperature.
• Moisture & dust resistant.
• Durable die-cast aluminum housing.
• Rugged construction which makes it ideal for use in outdoor spaces.
| Efficacy (lm/W) | Up to 131.17 lm/W |
| Power (W) |
Variant 1 - 21 W-28 W-34.98 W Variant 2 - 30 W-42 W-50.67 W Variant 3 - 72 W-100 W-114.8 W |
| CCT (K) | 3000 K - 4000 K - 5000 K |
| CRI | 70 |
| Voltage | AC 120-347, 120-277 V 50/60 Hz |
| Beam Angle | Up to 116.3° |
| Dimming | Continuous Dimming to 10% or Below |
| Operating Temperature | -40° F to +113° F |
| IP Rating | IP65 |
| Housing | Die Cast Aluminum |
| Power | SKU Number | CCT | Voltage | Type | Lumen Output | Beam Angle | Finish | Qualified part number | Ordering part number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 21 W-28 W-34.98 W | 662187481210 | 3000K - 4000K - 5000K | AC 120-347 V | Semi Cutoff | 2625 lm-3511.48 lm-4583 lm | 94.1° | Bronze | IK-WPBO3M-35W-304050K-PC | IK-WPBO3M-35W-304050K-PC | Download | Download |
| 30 W-42 W-50.67 W | 662187546988 | 3000K - 4000K - 5000K | AC 120-277 V | Semi Cutoff | 3750 lm-5509.14 lm-7031 lm | 116.3° | Bronze | IK-WPBO3M-50W-304050K-PC | IK-WPBO3M-50W-304050K-PC | Download | Download |
| 72 W-100 W-114.8 W | 662187546995 | 3000K - 4000K - 5000K | AC 120-277 V | Semi Cutoff | 9000 lm-12652 lm-15763 lm | 96.9° | Bronze | IK-WPBO3M-120W-304050K-PC | IK-WPBO3M-120W-304050K-PC | Download | Download |
