The IKIO Superia LED UFO High Bay provides multiple lumen packages and distributions. This fixture offers the necessary optical freedom and flexibility to meet the needs of a wide variety of lighting applications. It is a direct replacement of traditional HID fixtures.
| Efficacy (lm/W) | 180 lm/W |
| Power (W) | 100 W, 120 W, 150 W, 200 W |
| CCT (K) | 3000 K, 3500 K, 4000 K, 5000 K, 5700 K |
| CRI | 80+ |
| Voltage | AC 100-277 V 50/60 Hz |
| Beam Angle | 120° |
| Dimming | Optional |
| Operating Temperature | -10° F to +120° F |
| IP Rating | IP65 |
| Housing | Aluminum + Polycarbonate (Diffuser) |
| Power | SKU Number | CCT | Voltage | Lumen Output | Beam Angle | Finish | Diffuser | Qualified part number | Ordering part number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 100 W | 662187462783 | 4000 K | AC 100-277 V | 18000 lm | 120° | Black | Clear | Not Qualified Yet | IK-HBUF-L180-0100-DY-40 | Download | Download |
| 100 W | 662187553603 | 5000 K | AC 100-277 V | 18000 lm | 120° | Black | Clear | Not Qualified Yet | IK-HBUF-L180-0100-DY-50 | Download | Download |
| 120 W | 662187462790 | 4000 K | AC 100-277 V | 21600 lm | 120° | Black | Clear | Not Qualified Yet | IK-HBUF-L180-0120-DY-40 | Download | Download |
| 120 W | 662187553641 | 5000 K | AC 100-277 V | 21600 lm | 120° | Black | Clear | Not Qualified Yet | IK-HBUF-L180-0120-DY-50 | Download | Download |
| 150 W | 662187462813 | 4000 K | AC 100-277 V | 27000 lm | 120° | Black | Clear | Not Qualified Yet | IK-HBUF-L180-0150-DY-40 | Download | Download |
| 150 W | 662187548746 | 5000 K | AC 100-277 V | 27000 lm | 120° | Black | Clear | Not Qualified Yet | IK-HBUF-L180-0150-DY-50 | Download | Download |
| 200 W | 662187462844 | 4000 K | AC 100-277 V | 36000 lm | 120° | Black | Clear | Not Qualified Yet | IK-HBUF-L180-0200-DY-40 | Download | Download |
| 200 W | 662187553726 | 5000 K | AC 100-277 V | 36000 lm | 120° | Black | Clear | Not Qualified Yet | IK-HBUF-L180-0200-DY-50 | Download | Download |
