The IKIO Rodella UFO High Bay provides multiple lumen packages and distributions. This fixture offers the necessary optical freedom and flexibility to meet the needs of a wide variety of lighting applications. It is a direct replacement of traditional HID fixtures.
| Efficacy (lm/W) | 140 lm/W |
| Power (W) | 100 W, 150 W, 200 W, 240 W |
| CCT (K) | 3500 K, 4000 K, 5000 K |
| CRI | 70+ |
| Voltage | AC 100-277 V 50/60 Hz |
| Beam Angle | 120° |
| Dimming | 0-10 V, Range 10%-100% |
| Operating Temperature | -10° F to +120° F |
| IP Rating | IP65 |
| Housing | Aluminum |
| Power | SKU Number | CCT | Voltage | Lumen Output | Qualified part number | Ordering part number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|
| 100 W | 662187545301 | 4000 K | AC 100-277 V | 15000 lm | Not Qualified Yet | IK-HBP2-0100-40-DY-RLV01 | Download | Download |
| 100 W | 662187545325 | 5000 K | AC 100-277 V | 15000 lm | Not Qualified Yet | IK-HBP2-0100-50-DY-RLV01 | Download | Download |
| 150 W | 662187549453 | 4000 K | AC 100-277 V | 22500 lm | Not Qualified Yet | IK-HBP2-0150-40-DY-RLV01 | Download | Download |
| 150 W | 662187552163 | 5000 K | AC 100-277 V | 22500 lm | Not Qualified Yet | IK-HBP2-0150-50-DY-RLV01 | Download | Download |
| 200 W | 662187544809 | 4000 K | AC 100-277 V | 30000 lm | Not Qualified Yet | IK-HBP2-0200-40-DY-RLV02 | Download | Download |
| 200 W | 662187544830 | 5000 K | AC 100-277 V | 30000 lm | Not Qualified Yet | IK-HBP2-0200-50-DY-RLV02 | Download | Download |
| 240 W | 662187544939 | 4000 K | AC 100-277 V | 30000 lm | Not Qualified Yet | IK-HBP2-0240-40-DY-RLV02 | Download | Download |
| 240 W | 662187537245 | 5000 K | AC 100-277 V | 36000 lm | Not Qualified Yet | IK-HBP2-0240-50-DY-RLV02 | Download | Download |
| 100 W | 662187545295 | 3500 K | AC 100-277 V | 15000 lm | Not Qualified Yet | IK-HBP2-0100-35-DY-RLV01 | Download | Download |
| 150 W | 662187549446 | 3500 K | AC 100-277 V | 22500 lm | Not Qualified Yet | IK-HBP2-0150-35-DY-RLV01 | Download | Download |
| 200 W | 662187544793 | 3500 K | AC 100-277 V | 30000 lm | Not Qualified Yet | IK-HBP2-0200-35-DY-RLV02 | Download | Download |
| 240 W | 662187544922 | 3500 K | AC 100-277 V | 30000 lm | Not Qualified Yet | IK-HBP2-0240-35-DY-RLV02 | Download | Download |
