IKIO Locus Area Luminaire combines the duo of architectural form and versatility to make it an excellent choice for new construction or for retrofit applications. It is offered in a variety of wattages allowing for maximum flexibility in all types of applications. The high output LEDs and custom engineered optics provide excellent uniformity and efficiency. It is designed to replace the existing HID fixtures up to 1000 W.
| Efficacy (lm/W) | Up to 143 lm/W |
| Power (W) | 94.2 W, 142.3 W, 172.7W, 195 W, 230 W, 289.5 W |
| CCT (K) | 3000 K, 5000 K |
| CRI | 74 |
| Voltage | AC 100-277 V 50/60 Hz |
| Distribution | Type 3-M |
| Dimming | Yes |
| Operating Temperature | -40° F to +131° F |
| IP Rating | IP66 |
| Housing | Aluminum + Polycarbonate |
| Power | SKU Number | CCT | Voltage | Lumen Output | Finish | Ordering part number | Qualified part number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|---|
| 94.2 W | 662187539577 | 3000 K | 100-277 V | 13323 lm | Bronze | IK-SBSL1-0100-30-DY-RLV01-AI (Bronze T3) | IK-SBSL1-0100-30-DY-RLV01-AI | Download | Download |
| 94.2 W | 662187478098 | 5000 K | 100-277 V | 13323 lm | Bronze | IK-SBSL1-0100-50-DY-RLV01 (Bronze T3) | IK-SBSL1-0100-50-DY-RLV01-AI | Download | Download |
| 94.2 W | 662187539560 | 3000 K | 100-277 V | 13323 lm | White | IK-SBSL1-0100-30-DY-RLV01-AI (White T3) | IK-SBSL1-0100-30-DY-RLV01-AI | Download | Download |
| 94.2 W | 662187478104 | 5000 K | 100-277 V | 13323 lm | White | IK-SBSL1-0100-50-DY-RLV01 (White T3) | IK-SBSL1-0100-50-DY-RLV01-AI | Download | Download |
| 142.3 W | 662187478111 | 5000 K | 100-277 V | 20095 lm | Bronze | IK-SBSL1-0150-50-DY-RLV01 (Bronze T3) | IK-SBSL1-0150-50-DY-RLV01-AI | Download | Download |
| 142.3 W | 662187478128 | 5000 K | 100-277 V | 20095 lm | White | IK-SBSL1-0150-50-DY-RLV01 (White T3) | IK-SBSL1-0150-50-DY-RLV01-AI | Download | Download |
| 172.7 W | 662187539591 | 5000 K | 100-277 V | 23765 lm | Bronze | IK-SBSL1-0185-50-DY-RLV01-AI (Bronze T3) | IK-SBSL1-0185-50-DY-RLV01-AI | Download | Download |
| 172.7 W | 662187539584 | 5000 K | 100-277 V | 23765 lm | White | IK-SBSL1-0185-50-DY-RLV01-AI (White T3) | IK-SBSL1-0185-50-DY-RLV01-AI | Download | Download |
| 195 W | 662187478135 | 5000 K | 100-277 V | 27894 lm | Bronze | IK-SBSL1-0200-50-DY-RLV02 (Bronze T3) | IK-SBSL1-0200-50-DY-RLV02-AI | Download | Download |
| 195 W | 662187478142 | 5000 K | 100-277 V | 27894 lm | White | IK-SBSL1-0200-50-DY-RLV02 (White T3) | IK-SBSL1-0200-50-DY-RLV02-AI | Download | Download |
| 230 W | 662187478166 | 5000 K | 100-277 V | 32401 lm | Bronze | IK-SBSL1-0240-50-DY-RLV02 (Bronze T3) | IK-SBSL1-0240-50-DY-RLV02-AI | Download | Download |
| 230 W | 662187478173 | 5000 K | 100-277 V | 32401 lm | White | IK-SBSL1-0240-50-DY-RLV02 (White T3) | IK-SBSL1-0240-50-DY-RLV02-AI | Download | Download |
| 289.5 W | 662187478180 | 5000 K | 100-277 V | 41015 lm | Bronze | IK-SBSL1-0300-50-DY-RLV02 (Bronze T3) | IK-SBSL1-0300-50-DY-RLV02-AI | Download | Download |
| 289.5 W | 662187478197 | 5000 K | 100-277 V | 41015 lm | White | IK-SBSL1-0300-50-DY-RLV02 (White T3) | IK-SBSL1-0300-50-DY-RLV02-AI | Download | Download |
